Prevention of aflatoxin in pistachios1
MATERIALS AND METHOD
Chemicals and yeast
Aflatoxin B1 solution was purchased from Sigma Co. (St. Louis, MO, USA). Methanol, chloroform, acetone, n-hexane, acetonitrile, phosphate-buffered saline (PBS), and potassium bromide were supplied by Merck Co (Stutgart, Germany). Sodium alginate was obtained from BDH Co. (Dubai, UAE) and calcium chloride from Scharlau Co. (Germany). Saccharomyces cerevisiae (ATCC 9763) was obtained from a Persian-type culture collection in Iran.
Sample preparation
Akbari is the major pistachio cultivar grown in Iran; therefore, this cultivar was selected in this study. A freshly-harvested pistachio variety was purchased from Kerman, Iran. Pistachios were then subjected to de-hulling, trash and blank separation, unpeeled and unripe pistachio separation, washing, and sorting (to separate nuts from non-split ones). In order to achieve samples with lower moisture content, an identified mass of pistachio was dried by an oven equipped with a ventilator at 50 ºC. Finally, the samples were kept at -20 ºC in a freezer until the start of the experiments. 10 ppb and 20 ppb aflatoxin B1 solutions were prepared by adding phosphate-buffered saline (PBS) to pure aflatoxin. De-hulled pistachios were immersed in these solutions for 24 hours in order to contaminate them.
Culture preparation
A strain grown in yeast mold broth (YM Broth) tubes for 48 hours at 25 ºC was used as the inocula. Erlenmeyer flasks containing 100 mL of YM Broth were inoculated with the desired culture at a concentration of 102 cells/mL and incubated at 25 ºC until the cells reached an OD600 of 1.8 - 2 × 1010 cells/mL. Cells harvested at the required OD were centrifuged at 5000 × g for 10 min, washed twice with phosphate buffered saline (PBS, pH = 6.0), and spun again at 5000 × g for 10 min after each wash. Heat treated (autoclaved in 10 mL PBS at 120 ºC for 20 min) and acid treated (incubated at 25 ºC in 10 mL 2M HCl for 90 min with mild shaking) samples were washed twice with 4 mL PBS and centrifuged at 5000 × g for 10 min prior to use (2, 8).
Cell immobilization
Alginate solutions in a concentration range of 0.5-10% can be used for cell immobilization. Sodium alginate solution (3%) was prepared by dissolving sodium alginate in 100 mL boiling water and autoclaved at 121 ºC for 15 min. Cells were harvested in every manner of treatment, re-suspended in 2 mL of saline, and added to sterilize alginate solution. In order to immobilize the cells in alginate, pistachios were dipped in a 0.2 M CaCl2 solution (13).
Extraction and clean-up procedures for HPLC analysis
Samples were analyzed using a high performance liquid chromatography (HPLC) method (the AOAC official method 999.7). A ground pistachio sample (50 g) was blended with 2.5 g NaCl and a 200 mL solution of 80% methanol in water for 5 min. Then the mixture was filtered through Whatman filter paper. After filtration, the extract was diluted with water and filtered through a glass microfiber filter. Aflatest IACs were used to clean-up the samples. A 15 mL phosphate buffer saline (PBS) was first passed during the IAC. Then, 70 mL of the filtrate was passed through the IAC at a flow rate of ca.1 drop/s. The column was washed with 15 mL water and dried by application of vacuum. Finally, AF was eluted with methanol using the subsequent procedure. First, 0.5 mL of methanol was applied to the column and allowed to pass through by gravity. After 1 min, the second part of the 1 mL methanol was applied and collected. The eluate was diluted with water and analyzed by HPLC (2, 8).
Determination of aflatoxins by the HPLC method
Aflatoxins were isocratically separated using HPLC (Waters model 2475, USA), a fluorescence detector, and 50 µL of injected sample solution. The mobile phase was deionized water-acetonitrile-methanol (60:20:20, v/v) with the addition of350 µL of 4M HNO3 and 12 mg of KBr ata flowrate of1 mL/min. The fluorescence detector was set at an excitation wavelength of 362 nm and emission wavelength of 450 nm (2, 8). Quantification of each toxin was performed by measuring their peak areas and comparing them with their relevant standard calibration curve (retention time = 10.25 minutes, 0.035 ng < quantification < 0.405 ng, standard deviation = ± 0.001 ng), Percent binding was determined from the amount of unbound AFB1 remaining on the pistachio after incubation when compared to control (without yeast cells) before coating with alginate:
% bound= 100 [1-counts in the sample after coating / counts in control].
Microscopic examinations
Scanning electron microscopy (SEM) was used to study the morphology of the immobilized S. cerevisiae cells in alginate. The alginate was fixed on the pistachio samples. Finally, the samples were dried, coated with gold, and observed with a Philips XL 30 (Netherlands) microscope.
Color evaluation
Pistachio sample color L, a, and b values were measured by the Hunter Lab (Konica Minolta, Japan). Pistachio color was measured before and after coating with sodium alginate.
Determination of peroxide value
The peroxide value of the pistachio samples was measured before and after coating with sodium alginate to determine the peroxide value in fat content. Peroxide value (PV) was determined by the AOCS (1993) methods (3).
Texture study
Pistachio texture changes were measured by compressing samples with a Testometric (M350-10CT, Rochdale, England). The Maximum force (N) required to compress the sample was recorded as the firmness of the pistachio sample. Pre-test speed, test speed, and post-test speed were all set at 10 mm/min. Triplicates of each treatment were evaluated.
Statistical analysis
All of the analyses were done in triplicate sets belonging to three different batches. Values are represented as the mean values. Data were analyzed by ANOVA using Minitab 15 and the significance is expressed at a 5 % significance level (p < 0.05).
RESULTS AND DISCUSSIONS
S. cerevisiae cells were capable of binding large amounts of aflatoxin B1, even at the highest evaluated concentration (20 ppb). Yeast binding ability was largest when located in the exponential phase and under acidic conditions. Results indicate that the binding stage is a rapid process that saturates after 3 hours. Figure 1 indicates Aflatoxin binding at an exponential phase by means of S. cerevisiae ATTC 9763 was immobilized on pistachios with 10 ppb and 20 ppb AFB1. Figure 2 demonstrates that heating, even at 120 ºC for 20 min, could increase yeast binding ability to 55% and 75% with primary AFB1 concentrations of 10 and 20 ppb, respectively.
Heating may also raise the permeability of the external layer of the cell wall due to the suspension of some of the mannans from the cell surface, leading to the increased availability of the otherwise hidden binding sites. In addition, there will be countless physical-chemical changes taking place in the cell wall during the heat treatment, resulting in more exposed binding sites.
Figure 3 demonstrates the cell treatment under acid conditions could increase the binding ability to 60% and 73% for the two investigated concentrations of aflatoxin, respectively. It is possible that the acidic conditions could affect polysaccharides by releasing monomers, which are further fragmented into aldehydes after the breaking down of glycosidic linkages. Moreover, it was shown that increases in AFB1 concentration enhanced the binding ability of yeast cells. In comparison, among the three conditions (Figs. 2 and 3), the binding ability of yeast cells in acid and heat treatments are higher than those in the exponential phase. Furthermore, infrequent acid treatment is better than heat and acts in a similar manner.
ELISA results done by Hasakard, El-Nezami, Kakkaanpaa, Salminen, Ahokas (2001) showed that acidic treatment may cause intercellular binding, which might be a reason for the higher observed binding percent under acidic conditions versus other treatments. The better binding ability of the physically and chemically modified cells against the viable cells indicates a physical nature of binding rather than a metabolic process. Chromatographic analysis by Madrigal-Santilla´n, Madrigal-Bujaidar, Ma´rquez-Ma´rquez, Reyes (2006) showed similar densitograms between the AFB1 absorbed by yeast and an AFB1 standard. Additionally, absorption caused no structural changes in mycotoxin.
According to Bueno, Casale, Pizzplitto, Salvano, Oliver (2007), a physical absorption model is suggested for the binding of AFB1 to Saccharomyces cerevisiae. The model allows the evaluation of two parameters: the number of binding sites per microorganism (M) and the reaction equilibrium constant (Keq), both of which are valuable for estimating the adsorption effectiveness of a particular microorganism. They indicated that the M amount for yeast was 1×1011 sites/microorganism, and thus, we can consider it as a factor for AFB1 binding to yeast. The nature of the cell wall components involved in mycotoxin binding is still not clear. Carbohydrate-rich mannoproteins or glucans may be the likely candidates involved in the binding.
Effect of immobilization on the qualitative characteristics of pistachios Microstructure evaluation
Cells immobilized on pistachios were found to be suitable for aflatoxin binding at ambient temperatures. Cell immobilization on pistachio samples was proved by the ability of the immobilized S. cerevisiae to perform successive surface binding. Electron microscopy examination (Fig. 7) showed yeast cells immobilized in alginate solution.
Color
Appearance, particularly color, is one of the first attributes used by consumers for acceptability of a food. The data in Figure 4 represent the color parameters. L, a, and b values, which measure whiteness, redness, and yellowness, were 41.81, 13.38, and 14.98, respectively, for the samples without treatment with yeast (at t= 0); however, color values did not show any significant changes after coating with alginate and yeast during the exposure time. The appearance of the pistachios was still acceptable.
Peroxide value
The peroxide value represents the quality of pistachios, including fat content and freshness; however, peroxide values in Figure 5 did not show any significant changes after immobilization of yeast on pistachio samples during the experiment.
Texture
In this research, the immobilization of S. cerevisiae did not affect coated pistachios and did not cause any changes in texture. Figure 6 represents a punch experiment of pistachio samples before and after coating. Statistical analysis shows an analogous result for the pistachio samples. Hardness of the pistachio samples was 22.5% and 21.5% before and after the alginate coating, respectively. Minute differences between them may be due to variance in moisture after the alginate coating.
CONCLUSION
Results indicated that:
1) AFB1 binding to yeast was a rapid process.
2) The amount of AFB1 removed was related to toxin concentration.
3) Similar results were obtained with viable and nonviable (heat-treated and acid treated) yeast, confirming that the viability of the yeast was not a significant factor.
Results also showed that yeast immobilization on aflatoxincontaminated pistachios for toxin reduction had no effect on the qualitative characteristics of the nut, such as color, texture, and peroxide value. Furthermore, it was shown that the studied yeast strains were more efficient than the yeast strains in indigenous fermented foods, as seen by Shetty and Jesperson (2006).
Systematic studies with the intact cells and isolated cell walls are still needed to understand the chemistry of binding. Although the cell surface physical binding in general is a similar rapid phenomenon, kinetics of binding may differ. Stability of the yeast-aflatoxin complex under the harsh conditions of the gut has yet to be investigated; however, further studies are needed to identify the mechanism of binding, to identify the cell surface binding structures, and to study the constancy of the compound under physical-chemical conditions comparable to the conditions in the gastro-intestinal tract.
ACKNOWLEDGMENT
We would like to express our thanks to the "Iran Industrial Research and Standards Institution" and to "Research Council of the University of Tehran" for their financial assistance for this study.
REFERENCES
1. Abdulkadar, A.H.W.; Al-Ali, A.; Al-Jedah, J. (2000). Aflatoxin contamination in edible nuts imported in Qatar. Food Control, 11, 157-160. [ Links ] [ Links ]
3. AOCS (1993). Official methods and recommended practices of the American oil chemists society (4th ed.). Champaign, IL: AOCS Press. [ Links ]
4. Beta, A.; Lasztity, R. (1999). Detoxification of mycotoxin contaminated food and feed by microorganism. Trends in Food Science and Technology, 10, 223-228. [ Links ]
5. Bueno, D.J.; Casale, C.H.; Pizzplitto, R.P.; Salvano, M.A.; Oliver, G. (2007). Physical adsorption of aflatoxin B1 by Lactic acid bacteria and Saccharomayces cerevisiae: A theoretical model. J. Food Prot., 70 (9), 2148-2154. [ Links ]
6. Calvo, A.M. (2005). Mycotoxins. In Da˛browski, W. M., & Sikorski, Z.E, Toxins in food, 219-240, London, CRC PRESS. [ Links ]
7. Celyk, K.; Denyl, M.; Savas, T. (2003) Reduction of aflatoxin B1 by using baker yeast (Saccharomyces cerevisiae) in growing broiler chicks diet. R. Bras. Zootec., 23 (3), 615-619. [ Links ]
8. Cheraghali, A.M.; Yazdanpanah, H.; Doraki, N.; Abouhossain, G.; Hassibi, M.; Ali-abadi, S. (2006). Incidence of aflatoxins in Iran pistachio nuts. Food Chem. Toxicol., 45, 812-816. [ Links ]
9. Ghanem, I.; Orfi, M.; Shamma, M. (2008). Effect of gamma radiation on the inactivation of aflatoxin B1 in food and feed crops. Braz. J. Microbiol., 38, 787-791. [ Links ]
10. Hadavi, E. (2005). Several physical properties of aflatoxin-contaminated pistachio nuts: Application of BGY fluorescence for separation of aflatoxin-contaminated nuts. Food Addit. Contam., 22(11), 1144-1153. [ Links ]
11. Hasakard, C.A.; El-Nezami, H.S.; Kakkaanpaa, P.E.; Salminen, S.; Ahokas, J.T. (2001). Surface binding of aflatoxin B1 by Lactic acid bacteria. Appl. Environ. Microbiol., 3086-3091. [ Links ]
12. Janssen, M.M.T.; Put, H.M.C.; Nout, M.J.R. (1997). Natural toxins. In: Vries, J.D. (ed) Food Safety and Toxicity, CRC PRESS, London, England, p. 16-47. [ Links ]
13. Kourkoutas, Y.; Kanellaki, M.; Koutinas, A.A. (2006). Apple pieces as immobilization support of various microorganisms, LWT, 39, 980-986. [ Links ]
14. Madrigal-Santilla´n, E.; Madrigal-Bujaidar, E.; Ma´rquez-Ma´rquez, R.; Reyes. A. (2006). Antigenotoxic effect of Saccharomyces cerevisiae on the damage produced in mice fed with aflatoxin B1 contaminated corn. Food Chem. Toxicol., 44, 2058-2063. [ Links ]
15. Prado, G.; Pinheiro de Carvalho, E.; Silva Oliviera, M.; Cruz Madeira, J.G.; Morais, V. D.; Correa, R.F.; Cardoso, V.N.; Soares, T.V.; Moreira da Silva, J.F.; Pereira Goncalves, R.C. (2003). Effect of gamma irradiation on the inactivation of aflatoxin B1 and fungal flora in peanut. Braz. J. Microbiol., 34, 138-140. [ Links ]
16. Razavi, S.M.A.; Taghizadeh, M. (2007). The specific heat of pistachio nuts as affected by moisture content, temperature, and variety. J. Food Process Eng., 79, 158-168. [ Links ]
17. Sheibani, A.; Ghaziaskar. H.S. (In press). Pressurized fluid extraction for quantitative recovery of aflatoxins B1 and B2 from pistachio. Food Control (In press). [ Links ]
18. Shetty, P.H.; Jespersen, L. (2006). Saccharomyces cervisiae and lactic acid bacteria as potential mycotoxin decontaminating agents. Trends in Food Science and Technology, 17, 48-55. 19. [ Links ]
19. Shetty, P.H.; Hald, B.; Jespersen, L. (2006). Surface binding of aflatoxin B1 by saccharomyces cervisiae strains with potential decontaminating abilities in indigenous fermented foods. Int. J. Food Microbiol., 113 (1), 41-46. [ Links ]
Submitted: September 02, 2008; Returned to authors for corrections: March 03, 2009; Approved: August 22, 2009.
